The GIB series: Air-cooled high-pressure booster for the Gas Injection Technology
BAUER High-pressure booster
Opis
| Type
designation |
Effective
free air delivery ¹ |
Intake
pressure |
Operating pressure ² | No. of
compr. stages |
Speed
approx. |
Motor
output |
Power
consumption ¹ |
Net weight approx. | ||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| l/min | m³/h | cfm | barg | bar | psig | rpm | kW | kW | kg | lbs | ||
| GIB 12.2-5.5-MV | 200 | 12 | 7 | 5 | 365 | 5300 | 2 | 1230 | 5.5 | 3.3 | 333 | 734 |
| 295 | 17.7 | 10.4 | 7 | 4.0 | ||||||||
| 390 | 23.4 | 13.8 | 9 | 4.6 | ||||||||
| 475 | 28.5 | 17 | 11 | 5.1 | ||||||||
| Type
designation |
Effective
free air delivery ¹ |
Intake
pressure |
Operating pressure ² | No. of
compr. stages |
Speed
approx. |
Motor
output |
Power
consumption ¹ |
Net weight approx. | ||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| l/min | m³/h | cfm | barg | bar | psig | rpm | kW | kW | kg | lbs | ||
| GIB 15.3-11-V | 510 | 30.6 | 18 | 7 | 365 | 5300 | 2 | 1140 | 11 | 6.6 | 404 | 891 |
| 590 | 35.4 | 20.8 | 8 | 7.1 | ||||||||
| 670 | 40.2 | 23.7 | 9 | 7.7 | ||||||||
| 750 | 45 | 26.5 | 10 | 8.2 | ||||||||
| GIB 15.41-15-V | 430 | 25.8 | 15.2 | 2 | 365 | 5300 | 3 | 1350 | 15 | 9.0 | 416 | 917 |
| 590 | 35.4 | 20.8 | 3 | 10.6 | ||||||||
| 750 | 45 | 26.5 | 4 | 12.1 | ||||||||
¹ Free air delivery according to ISO 1217, power consumption at maximum final pressure under certain conditions. Other ambient conditions result in different performance data. Values valid for 50 Hz.
² Max. operating pressure = max. safety valve pressure setting; reduced switch-off pressure.
